Safety for CNC machines

Safety (pressure-sensitive) mats, bumpers and edges for CNC machinery

Safety for CNC machines

Safety (pressure-sensitive) mats, bumpers and edges for CNC machinery

The numerical control machines (MCN), in English computerized numerical control machine, also called CNC machines (Computerized Numerical Control), are machine tools that use a computerized numerical control.

Condividi via:

The numerical control machines (MCN), in English computerized numerical control machine, also called CNC machines (Computerized Numerical Control), are machine tools that use a computerized numerical control.

CNC machines are widely used in almost every field of mechanics, such as in the case of press brakes, punching machines, lathes, milling machines, welding machines and sheet metal cutting machines (laser, oxy-fuel, plasma, water jet, pantographs, drilling machines, etc.).

Numerical machine manufacturers are often confronted with the sensitive issue of machine safety requirements. The safety risks are determined through a systematic analysis of the single events potentially dangerous for people, in the various operating modes of the machines.

CNC machines are widely used in almost every field of mechanics, such as in the case of press brakes, punching machines, lathes, milling machines, welding machines and sheet metal cutting machines (laser, oxy-fuel, plasma, water jet, pantographs, drilling machines, etc.).

Numerical machine manufacturers are often confronted with the sensitive issue of machine safety requirements. The safety risks are determined through a systematic analysis of the single events potentially dangerous for people, in the various operating modes of the machines.

The safety regulations

Where the risk cannot be considered acceptable, specific safety measures must be taken to ensure that the hazards are minimized. In particular, in the EU, the main directives for CNC manufacturers are:

Where the risk cannot be considered acceptable, specific safety measures must be taken to ensure that the hazards are minimized. In particular, in the EU, the main directives for CNC manufacturers are:

The safety regulations

How do numerical control machines work?

In CNC machines it is possible to distinguish between two broad categories of operation.

Automatic operation is that in which the machine performs its functions without any intervention by the operator. In this case the machine is made safe by adopting safety devices such as metal fences or protective barriers in plastic materials.

Semi-automatic operation Semi-automatic operation is that in which the machine performs its functions with the intervention of the operator in the loading, unloading and tool changing phases while it operates automatically for the rest of its functions. In semi-automatic operating mode then safety devices such as sensitive mats, bumpers, sensitive edges or vision devices come into play, protecting operators and all personnel involved in the production from any risk of injury.

How do numerical control machines work?

In CNC machines it is possible to distinguish between two broad categories of operation.

Automatic operation is that in which the machine performs its functions without any intervention by the operator. In this case the machine is made safe by adopting safety devices such as metal fences or protective barriers in plastic materials.

Semi-automatic operation Semi-automatic operation is that in which the machine performs its functions with the intervention of the operator in the loading, unloading and tool changing phases while it operates automatically for the rest of its functions. In semi-automatic operating mode then safety devices such as sensitive mats, bumpers, sensitive edges or vision devices come into play, protecting operators and all personnel involved in the production from any risk of injury.

Area sensors: pressure-sensitive safety mats

Area sensors: pressure-sensitive safety mats

An optimal safety configuration must allow maximum efficiency and productivity, while ensuring total safety. Pressure-sensitive safety mats, for example, act as area sensors that are activated when stepped on. They are typically placed around the perimeter of the machines. Depending on the type of application, the mats can be configured in zones, so that it is always possible to define areas with differentiated risk.



The differentiated zone configurations make WIDE Automation safety mats perfectly adaptable to any type of machine and environment, thanks to the resistance to water and dust (IP65) and easy maintenance and cleaning.

An optimal safety configuration must allow maximum efficiency and productivity, while ensuring total safety. Pressure-sensitive safety mats, for example, act as area sensors that are activated when stepped on. They are typically placed around the perimeter of the machines. Depending on the type of application, the mats can be configured in zones, so that it is always possible to define areas with differentiated risk.



The differentiated zone configurations make WIDE Automation safety mats perfectly adaptable to any type of machine and environment, thanks to the resistance to water and dust (IP65) and easy maintenance and cleaning.

Shockproof safety for moving heads

Shockproof safety for moving heads

Installed on the moving part of the machine, safety bumpers make the operator safe, guaranteeing a collision in the event of an impact without consequences for his health and safety.

Installed on the moving part of the machine, safety bumpers make the operator safe, guaranteeing a collision in the event of an impact without consequences for his health and safety.

They can also be used in pairs with safety mats or with other safety devices (optical barriers) which reduce the moving speed of the moving part, reducing its danger to allow the bumper to be fully effective.
It is possible to customize the bumpers in shape, sensitivity and size, so that people are always protected, and downtimes are always controlled.

They can also be used in pairs with safety mats or with other safety devices (optical barriers) which reduce the moving speed of the moving part, reducing its danger to allow the bumper to be fully effective.
It is possible to customize the bumpers in shape, sensitivity and size, so that people are always protected, and downtimes are always controlled.

Safe enclosed machines and automatic doors
with sensitive edges

Safe enclosed machines and automatic doors

They are used in the case of enclosed machines that have operator access to the work area through an automatically closing door. In this case, sensitive edges serve to protect operators from sharp or pointed edges, which can cause crushing or cutting risks.

They are used in the case of enclosed machines that have operator access to the work area through an automatically closing door. In this case, sensitive edges serve to protect operators from sharp or pointed edges, which can cause crushing or cutting risks.

The sensitive edge is nothing more than a hollow chamber profile with a sensitive element inside it. If it encounters an obstacle, for example a hand, in the way of closing a door, it produces an electrical signal capable of interrupting or reversing the movement (i.e. automatic closing), which can be processed by special electronic control units.

The sensitive edge is nothing more than a hollow chamber profile with a sensitive element inside it. If it encounters an obstacle, for example a hand, in the way of closing a door, it produces an electrical signal capable of interrupting or reversing the movement (i.e. automatic closing), which can be processed by special electronic control units.

Profiles, shapes (angular, curved, shaped, etc.) and sensitivities are some of the parameters carefully studied together with the customer, to make up a product that integrates perfectly with the machine.

Profiles, shapes (angular, curved, shaped, etc.) and sensitivities are some of the parameters carefully studied together with the customer, to make up a product that integrates perfectly with the machine.

Want to know more?
Please ask.

Want to know more?
Please ask.

Our technicians will be able to provide you with all the information you need.
